Specification

DID-05

DID-4

Measuring range

2.0 - 500 mN-m

0.020 - 4 N-m

0.020～5 kgf-cm

0.20～40 kgf-cm

0.020～4.5 lbf-in

0.20～35 lbf-in

Accuracy

± 0.5% (in case of reading 499 or less = last digit +/- 3 reading)

Display

The 4 figures digital display of LCD

The measurement direction

CW-CCW (right and left)

Measuring
mode

P-P  Peak

Holding Peak Load Value

T-R  Track

Showing Real time torque value ( Used for Zero-Adjustment )

P-D  Peak down

Holding Load Value at the moment to change from upward to downword

C Real-time output

Load torque value is outputted every about 1/ 160.

Decision
function

Setting of torque value

Programmable High and Low setpoints with both audible beep and Green/Red LED indicator for uniform torque tightening or GO/NO GO testing

The Maximum, the minimum, and the average value

The data number, the maximum, the minimum value, and the average value of memory data are displayed.

Data spec.

Data transfer

ASCII format (Baud rate : 19200)
When outputting data,the cable(USB miniB) is needed.

Data memory

800 data

A setup of the number of counts

One to 99 count   (count in a direction with a bundle)

Power supply

Ni-MH chargeable battery 1.2V×4cells 800mAh

Auto power save

10 minutes no use, automatically switch off.

Charging time

From empty - less than 5hours

Continunous working time

12 hours

Bit /Socket part

φ4

HEX6.35

Weight

about 180g

about 400g

Attachment

Bit （＋） ＃１
For one-wey ×1 For fixation×1

Bit （＋） ＃１ ＃２

Accessories
 (one piece each)

AC/DC Adaptor (Charger)

An inspection report, a proofreading certificate, a traceability system figure
